The weather is really insanely hot. It’s the kind of weather where you can’t live a day without air conditioning. This year, it really seems like we should leave the air conditioner on all summer long. If you use the air conditioner a lot like this, it will cause a lot of trouble. And when it breaks down at the moment, it’s very embarrassing.
In particular, most of the time the wind suddenly weakens or cool wind does not come out. So today, let’s briefly look at how to check and solve Samsung air conditioner error codes that many people are using recently. Please take a good look at the picture. 삼성 에어컨 에러코드
1. If a picture appears on the display
This is a case where a picture appears instead of the error code of the Samsung air conditioner. 좋은뉴스
This is the case when a picture mark appears on the display part of the Samsung air conditioner (the part where text or pictures are displayed). First, when the picture of the air conditioner filter display appears, it is a ‘filter cleaning request’. The dust filter should be cleaned once every two weeks.
And when the picture that becomes clean with the wind appears, it is ‘self-cleaning drying mark’. The air conditioner will automatically turn off after completing the cleaning process. If a picture of a code appears, it’s a ‘sleep indicator’. This is displayed when the outdoor unit is in power saving mode.
2. CF and CI codes
CF and CI air conditioner error codes
The air conditioner code ‘CF’ has the same meaning as the ‘filter cleaning mark’ mentioned above. Similarly, you can clean the dust filter once every two weeks. ‘CI’ is also the ‘self-cleaning drying mark’ mentioned above. After the automatic cleaning is completed, the product automatically turns off.
The codes I’ve seen so far are codes that are a little far from faulty. If you get the above code, don’t worry too much. Then, from now on, let’s take a look at the Samsung air conditioner error codes that many people are confused about.
3. C1 code
C101~C176 Samsung air conditioner error codes.
First is ‘C101’. This code is ‘indoor/outdoor unit communication check’ code. This code appears when the outdoor unit power cord is disconnected or not properly connected. Or you can check if the earth leakage breaker is up.
The ‘C134’ code is the ‘shutter sensor check’ code. In this case, a sensor inspection by an engineer is required. However, it is not urgent because it is an air conditioner error code that does not affect cooling performance.
‘C154’ is the code for ‘Inspection of the indoor fan at the top of the stand type’. Appears when there is a problem with the fan inside the indoor unit. If this code comes out, disconnect the power cord of the air conditioner, turn off the breaker, then raise the breaker again and plug in the power cord to connect.
‘C155’ is the code for ‘inspect the indoor fan in the middle of the stand type’ and ‘C176’ is the code for ‘inspect the indoor fan in the lower part of the stand type’. Reconnecting everything as described above usually solves the problem.
The last ‘C163’ code is the ‘option check’ code. In this case, you need to set the indoor unit option again. You can call the Samsung Air Conditioner Error Code Customer Center number at 1588-3366 and inquire.
4. C4 Chord
C404~C465 Samsung air conditioner error codes.
The following Samsung air conditioner error codes are C4 series. Let’s look at each one. ‘C404’ is the ‘Overload Protection Control’ code. This may occur temporarily due to an outdoor unit overload. If this error code appears, you need to cool the temperature of the outdoor unit by installing a sunshade or spraying water on the outdoor unit.
The ‘C416’ code is the ‘discharge part protection control’ code. First, after checking the installation condition of the outdoor unit, install a shading film as above or spray water to cool the outdoor unit. The ‘C422’ code is the ‘EEV valve plugged’ code. In this case, you need to check whether the service valve is open. And after making sure there are no leaks, turn off the air conditioner and turn it on again.
‘C463’ and ‘C465’ are protection control codes. The two codes often appear temporarily due to overloading of the outdoor unit. It often appears when the air conditioner is running for a long time. Even in this case, installing a shading film on the outdoor unit can reduce the occurrence of error codes, and if it is difficult to install a shading film, spray water to cool the outdoor unit.
5. C5 code
C5 Samsung air conditioner error code.
Finally, the C5 chord. ‘C554’ and ‘C574’ codes are ‘refrigerant level check’ and ‘refrigerant leak check’ respectively. In this case, you can check the amount of odor after checking the pipe connection condition and leakage.
6. If not resolved
If you can’t solve the problem after looking at the code description above, you have no choice but to call an air conditioner repair technician. Reservations can be made through the website, phone, or mobile phone, and you can make a reservation by looking at the service sticker attached to the air conditioner. The driver will visit you about 2-3 days after booking.
Most of the cases where the driver visits are when parts need to be replaced or repairs due to old age or breakdown are needed. Depending on the situation, travel expenses and repair costs may be incurred, and in the case of an air conditioner that has been used for a long time, repair costs of 50,000 won to 100,000 won may be incurred. However, except for severe cases, most cases can be resolved by taking the measures described above.
